XIR C2660/C2620/C1200 SERIES

Easy to use, easy to migrate

Simple and effective for the light user who values ease and efficiency. Easy to use and practical, the XiR C2660/C2620/C1200 radios offers analog voice communications, and MOTOTRBO digital when you’re ready — for a straightforward path to digital migration.

XIR C2660/C2620/C1200 SERIES BROCHURE

Category:

Description

Features

Versatile solution for today and tomorrow

Offering between 16 and 160 channels, the XiR C2660/C2620/C1200 Series includes radios with limited keypad and non-keypad, as well as, display and non-display models. The ability to operate in both analog and digital modes also makes it easy and affordable to adapt your new digital radios to work along with your existing analog radios. You can migrate to a digital two-way radio platform at your own pace.

Clearer audio, better performance

When it comes to exceptional audio clarity, the quality of digital cannot be denied. The XiR C2660/C2620/C1200 Series radios give you digital audio performance throughout your coverage area. The digital voice processing with enhanced call signalling ensures faster and more reliable calls. When your workers cannot be distracted, voice announcement provides audible confirmation of channel changes, as well as programmable buttons that eliminate the need to view the radio display.

Increased efficiency without increased costs

Powered by the Time Division Multiple Access (TDMA) digital technology, your XiR C2660/C2620/C1200 radios provide twice the calling capacity as analog for the price of one frequency license. The XiR C2660/C2620/C1200 Series features the Dual Capacity Direct Mode that unlocks the full capacity of your digital radio system by doubling your channels without the cost of a repeater and its associated infrastructure.

Features

  • Analog / Digital Voice Communications
  • Voice Announcement
  • Dual Capacity Direct Mode
  • Pre-programmed Text Messaging
  • Transmit Interrupt (Decode only)
  • Digital Mobile Radio (DMR) Standards Compliant1
  • IP54 Rated
  • IP Site Connect

Performance Characteristics

Power output

1W/4W – UHF/350MHz
1W/5W – VHF

Battery life (based on a 05/05/90 duty cycle)

Li-Ion 1700mAh Battery : Analog: 10.7 hrs / Digital: 14.4 hrs
High Cap Li-Ion 2250mAh : Analog: 15.0 hrs / Digital: 20.0 hrs

Standard battery chemistry type

Lithium Ion

Frequency range

136-174 Mhz / 350-400 MHz / 403-480 MHz

Battery life (based on a 05/05/90 duty cycle)

Li-Ion 1700mAh Battery : Analog: 10.7 hrs / Digital: 14.4 hrs
High Cap Li-Ion 2250mAh : Analog: 15.0 hrs / Digital: 20.0 hrs

Standard battery chemistry type

Lithium Ion

Power output

1W/4W – UHF/350MHz
1W/5W – VHF

Radio Features

Channel spacing (kHz)

12.5, 25

User Environment

Operating temperature

-30C / +60C

Mil spec

810 C, 810 D, 810 E, 810 F, 810 G

IP Standards

IP54
