Description
Features
Connected
The MOTOTRBO XiR P6600i Series is a family of DMR-standard digital radios that delivers operations-critical voice communications. With support for basic trunking as well as legacy analogue technology, you can keep your organisation connected as it grows.
Efficient
With new noise cancellation technology and enhanced clarity, the XiR P6600i Series delivers excellent audio quality to make your workplace communications clearly intelligible. The latest energy technology provides the battery option which delivers up to 28 hours of battery life for 3-shift working, and the optional IMPRES Over-the-Air Battery Management tool helps you maximise battery lifetime. An improved receiver boosts range, allowing you to reach further than ever.
Safe
The XiR P6600i Series is designed to improve safety in your organisation, with the rapid response capability of instant push-to-talk communications. Even if a worker is unresponsive, you can remotely activate the radio to check that your worker is safe. Radios can be remotely disabled if they are misplaced. New HazLoc models are available for use in areas where flammable or explosive materials are present.
Performance Characteristics
Standard battery chemistry type
Lithium Ion
Battery life (based on a 05/05/90 duty cycle)
Digital/Analog Battery Life, Standard 1600 mAh Battery
XiR P6620i VHF: 16.0 / 11.5 hrs
XiR P6620i 350: 15.0 / 11.5 hrs
XiR P6620i UHF: 15.0 / 11.5 hrs
XiR P6600i VHF: 16.0 / 11.5 hrs
XiR P6600i 350:15.0 / 11.5 hrs
XiR P6600i UHF: 15.0 / 11.5 hrs
XiR P6620i VHF: 19.5 / 14 hrs
XiR P6620i 350: 18.5 / 14 hrs
XiR P6620i UHF: 18.5 / 14 hrs
XiR P6600i VHF: 19.5 / 14 hrs
XiR P6600i 350: 18.5 / 14 hrs
XiR P6600i UHF: 18.5 / 14 hrs
XiR P6620i VHF:28.5 / 21 hrs
XiR P6620i 350: 27.5 / 21 hrs
XiR P6620i UHF: 27.5 / 21 hrs
XiR P6600i VHF: 28.5 / 21 hrs
XiR P6600i 350: 27.5 / 21 hrs
XiR P6600i UHF: 27.5 / 21 hrs
Repeater capable
Yes
Power output
1W/4W – UHF
1W/5W – VHF
Frequency band
UHF, 350 MHz, VHF
Physical Characteristics
Dimensions H x W x D (with standard battery)
4.8 x 2.2 x 1.4 in (122 x 56 x 36 mm)
Weight (with standard battery)
XiR P6620i: 10 oz (281 g)
XiR P6600i: 9 oz (264 g)
Display
Limited
Radio Features
-
Busy channel lockout
Yes
-
Call tones
Yes
-
Channel scan
Yes
-
Channel spacing
12.5, 25
-
Missed call alerts
Yes
-
Group call
Yes
-
Scan types
Normal, Priority, Dual priority, Nuisance channel delete, Talk group, All group, System, Home revert
-
Time out timer
Yes
-
Programmable buttons
Yes
-
Signalling
MDC (Encode/Decode), Quik-Call II (Encode/Decode)
-
Lone worker
Yes
-
Private line
Yes
-
Transmit interrupt
Optional
-
Call forward
Yes
-
Caller ID
Yes
-
Number of channels
Limited Keypad (LKP) Models – 128 channels
No Keypad (NKP) Models – 32 channels -
CPS (Customer Programming Software)
Yes
-
One to one calling
Yes
-
Phone book
Yes
-
Talkaround
Yes
-
Voice operated transmit (VOX)
Yes
-
Intelligent audio
Yes
-
Voice announcement
Yes
-
Monitor Permanent (Sticky) Monitor
Yes
-
Digital private line
Yes
-
Enhanced privacy
Optional
Technology
-
Digital technology
Yes
-
System type
Conventional, Capacity Plus, IP Site Connect, Linked Capacity Plus
User Environment
-
Mil spec
810 C, 810 D, 810 E, 810 F, 810 G
-
IP Standards
IP67
Warranty
-
Standard warranty
2 years
